DEERE AT196470 Boom Cylilnder Seal Repair Kits for Excavator 490E

Ask Lasest Price
Brand Name :	SUNCAR
Model Number :	AT196470 Boom cylinder seal repair kit
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union,
Supply Ability :	550 Sets Per Week.
Delivery Time :	3-7 Days After Payment Received(Public Holiday Excluded)

Add to Cart

Product Details
Company Profile

DEERE AT196470 Boom Cylilnder Seal Repair Kits for Excavator 490E

DEERE AT196470 Boom Cylilnder Seal Repair Kits for Excavator 490E

Description: AT196470 DEERE boom cylinder seal repair kits.

Product name	DEERE AT196470 Boom Cylilnder Seal Repair Kits for Excavator 490E
Brand name	SUNCAR
OEM number	AT196470
AppliC-A-Ted models	DEERE 490E
Fit Brand	JOGH DEERE;
MOQ	Accept trial order
Temperature	-40°C ~ 250 °C.
Material	PU;VMQ;ACM;NBR;HNBR,;PTFE;Rubber
Function	Dust proof, Shaft seal,high and low temperature resistance
Material	PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ
Medium	Hydraulic oil, anti-fire fluid, water, gas etc
Feature	High temperature, low temperature, high pressure, low pressure, friction resistance
Transport mode	By Air, by Sea, by Express ( FedEx , UPS,DHL,TNT etc.), your forwarder
CertifiC-A-Tion	ISO9001
Market	Those in need
Availability	In stock
AppliC-A-Tion	Excavator machinery, Logger;DEERE;Consturction machinery repair store;Resell store
Color	Standard color
Condition	A brand-new, unused, unopened, undamaged
Style	Hydraulic arm cylinder seal kit

Hydraulic cylinder seal kits are used to seal the gap between different parts of the hydraulic cylinder. The function of hydraulic cylinder seal kits is

to prevent oil leakage, to assure the working pressure of the hydraulic system, to maintain its power.

Boom Cylinder seal kit is, as the name suggests, fitted into the boom cylinder.

There are regularly three cylinders for the excavator, boom cylinder, arm cylinder, bucket cylinder.

Arm cylinder is the top one, and it's usually be called as top cylinder;

The bucket cylinder is the one that connects and controls the bucket.

Boom cylinder is the one (or the two) near the cabin. Usually, there is one piece boom cylinder for the small excavator under 10-tun; the bigger

excavator's two pieces boom cylinders. But there is an exception too when the driver will remove one piece for a special purpose, say at some

particular working place, it is convenient to work by one cylinder. Soft remind: all refit job should be operated by an experienced technician.

Relative Parts:

Pos.	Part No	Qty	Parts name
0	4286454J	[1]	Hydraulic Cylinder
0	........	[1]	Hydraulic Cylinder
1	4286458	[1]	Structural Tubing
1A.	3051399	[1]	Bushing
2	4286456	[1]	Rod
2B.	140808	[1]	Bushing
3	408803	[1]	Cylinder Head
4	AT133645	[1]	Bushing
5	271304	[1]	Snap Ring
6	AT153914	[1]	Ring
7	AT264256	[1]	Packing
8	AT264257	[1]	Back-Up Ring
9	H158453	[1]	Scraper Ring
10	AT264319	[1]	O-Ring
11	TH109318	[1]	Back-Up Ring
12	408805	[12]	Screw
13	408806	[1]	Bearing
14	408807	[1]	Seal
15	H158463	[1]	Piston
16	AT264387	[1]	Ring
17	AT153919	[2]	Back-Up Ring
18	AT309607	[2]	Ring
19	AT264388	[2]	Ring
20	TH109328	[1]	Shim
21	310511	[1]	Nut
22	22M6684	[1]	Set Screw
23	T13624	[1]	Ball
26	TH100074	[1]	LubriC-A-Tion Fitting
39	TH104472	[4]	Seal
40	AT196470	[1]	Seal Kit
57	AH234632	[1]	Oil Line
57	4680347G	[1]	Pipe
57A.	94-2013	[1]	Fitting Plug
57A.	94-2013	[1]	Fitting Plug
58	........	[1]	Tube
58	408813	[1]	Tube
59	........	[2]	O-Ring
60	19M8213	[4]	Screw
60	19M8337	[4]	Screw
61	T116311	[4]	Bolt
61	19M8439	[4]	Screw
62	408814	[1]	Band
63	310707	[1]	Band
64	19M7550	[2]	Cap Screw
65	12M7066	[2]	Lock Washer
66	TH109337	[2]	Clamp
67	19M8348	[1]	Cap Screw
68	12M7058	[1]	Lock Washer
69	4174541	[1]	Fitting
69A.	4506418	[1]	O-Ring
50	961438	[3]	Clamp
51	961439	[2]	Bolt
52	961236	[2]	Washer
53	961440	[4]	Bolt
54	961236	[4]	Washer
55	4640118	[1]	Seal Kit
70	AT330599	[1]	Field Installation Kit
70	AT336163	[1]	Field Installation Kit
